Kontio Solar Inverter, 15kW, 3-phase, 380V, 50Hz

0.0

The powerful and reliable Kontio Solar 15 kW On-Grid Inverter is designed to maximize the benefits of your solar panels. As a leading technology provider, we offer a top-class On-Grid inverter suitable for both residential and commercial solar power plants. The Kontio Solar 15 kW On-Grid Inverter is the perfect solution for efficient, high-performance solar energy systems, ensuring you get the most out of your solar investment.

Tnot inc. VAT.

1 096,63 €1 286,84 €

Amount

Product code: KON-KS00015

TOP-CLASS TECHNOLOGY

The Kontio Solar On-Grid inverter offers an efficiency of over 99%. It reliably converts direct current (DC) from solar panels into alternating current (AC), ready for grid feed-in. This high-quality inverter boosts voltage to 400 volts in 3 phases, ensuring efficient and stable energy production.

BEST CHOICE FOR 3-PHASE SYSTEMS

The Kontio Solar 15 kW inverter provides a clear advantage in 3-phase systems. Unlike single-phase alternatives, the three-phase inverter ensures optimal power distribution, enabling efficient electricity use with minimal losses.

COMPATIBLE WITH MORE PANELS

Looking to maximize your investment? The Kontio Solar 15 kW inverter can be connected to up to 40 solar panels. With a maximum input power of 19.5 kW and an active AC output power of 16.5 kW, it ensures high-efficiency energy production.

EASY CONTROL WITH WIFI CONNECTIVITY

Monitor and manage your inverter effortlessly by connecting via WiFi. Track your energy production and optimize system performance anytime, anywhere.

Product specifications:

Maximum DC Input Power: 19.5 kW
Maximum DC Input Voltage: 1000 V
Startup DC Input Voltage: 250 V
MPPT Operating Voltage Range: 200-850 V
Maximum DC Input Current: 13 + 26 A
Maximum Short Circuit Current: 19.5 + 39 A
Number of MPPT Trackers: 2
Strings per MPPT Tracker: 1 + 2
Nominal Output Power: 15 kW
Maximum Active Power: 16.5 kW
Nominal Output Voltage/Range: 3L/N/PE 220/380V, 230/400V
Nominal Grid Frequency: 50/60 Hz (optional)
Operating Phase: Three-phase
Nominal AC Output Current: 22.7/21.7 A
Maximum AC Output Current: 25/23.9 A
Power Factor: 0.8 (leading to 0.8 lag)
Grid Current THD: <3%
DC Injection Current: <0.5%
Grid Frequency Range: 4555 or 5565 Hz (optional)
Maximum Efficiency: 98.5%
European Efficiency: 97.5%
MPPT Efficiency: >99%
DC reverse polarity protection
AC short circuit protection
AC output overcurrent protection
Output overvoltage protection
Insulation resistance monitoring
Ground fault monitoring
Anti-islanding protection
Temperature protection
Integrated DC switch
Remote software updates
Remote parameter modification
Surge Protection: DC Type 2 / AC Type 2
Brand: Kontio Solar
Country of Manufacture: China
GTIN Code: 6438431035522
Height: 185 mm
Width: 457 mm
Depth: 330 mm
Weight: 15 kg
Color: White
Topology: Transformerless
Internal Consumption: <1W (night)
Operating Temperature: -25°C to +65°C
Noise Level: ≤40 dB
Cooling Concept: Intelligent cooling
Maximum Operating Altitude: 4000 m
Grid Connection Standards: VDE4105, IEC61727/62116, VDE0126, AS4777.2, CEI021, EN50549-1, G98, G99,
C10-11, UNE217002, NBR16149/NBR16150
Environmental Humidity: 0-100%
Safety & EMC Standards: IEC/EN61000-6-1/2/3/4, IEC/EN62109-1, IEC/EN62109-2
MC-4 Compatible
IP65 Rated Plug
Display: LCD1602
Interfaces: RS485 / RS232 / WiFi / LAN
