HARVIA XENIO CX170WIFI, CX1704XW

Harvia Xenio is a control panel with a touch panel for an electric heater with a power of up to 17 kW. In addition to the heater, you can also control the lighting and ventilation of the sauna. The set includes a control center, a power supply unit, a temperature sensor with a 4 m cable and a 5 m data cable. If the control panel is equipped with an additional power supply unit LTY17, it can control heaters with a power of up to 34 kW. With the MyHarvia app, the functions of the sauna can be adjusted wirelessly. Sauna functions can be controlled remotely with a suitable door sensor and heater safety equipment.
The stylishly small but convenient panel can be easily installed in the sauna or laundry room, the front room or the living room. The panel can be installed both on the wall and recessed. The power supply unit is installed in a dry place outside the sauna room.

Control panel

• Temperature adjustment range: 40-110 °C
• Working time regulation area: family saunas 1-6 h, public saunas in apartment buildings 1-12 h
• Pre-tuning time adjustment range: 0-12 h
• Lighting and fan control
• Dimensions: 85mm x 24mm x 110mm
• MyHarvia mobile application (GooglePlay and AppStore)

Contactor box

• Supply voltage: 400 V 3-phase
• Maximum power from the control center to the heater: 17 kW
• Lighting control, maximum power: 100 W, 230 V single phase
• Fan control, maximum power: 100 W, 230 V single phase
• Dimensions: 272mm x 70mm x 193mm

Temperature sensor with 4 m cable

• The temperature sensor is equipped with a resettable overheating protection and a temperature-measuring NTC thermistor (22 kΩ/T=25 °C).
• The WX325 humidity sensor measures temperature and relative humidity
• Weight: 175 g with cables (approx. 4 m)
• Dimensions: 51mm x 73mm x 27mm
  Data cable 5 m, with 10 m extension cord

Manual
